Standard Features
- Clack 1191 In and Out Valve
- Non-Corrosive UV-Resistant Valve Body
- Structural® Heavy Duty Fiberglass Tank
- Heavy Duty Riser Pipe and Lower Screen
- Gel Poly Styrene Crosslinked with DVB
Options and Upgrades
- 90° Extensions and Bypass Valve
- Various Connection Sizes Available
- Stainless Steel Jacket
SPECIFICATIONS
| Part Number | Valve | Connections | Media | Tank Size | Cubic Feet | Tank Quantity | Maximum Recomended Service Flow | Estimated Peak Flow | Shipping Weight | System Assembled |
|---|---|---|---|---|---|---|---|---|---|---|
| 205621 | 1191 | 1″MNPT | 60% Gd Poly Styrene crosslinked with 40% DVB | 9 x 48 | 1 | 1 | 4.0 gpm | 12.0 gpm | 110 lbs | Assembled |
| 205622 | 1191 | 1″MNPT | 60% Gd Poly Styrene crosslinked with 40% DVB | 10×54 | 1.5 | 1 | 6.0 gpm | 14.0 gpm | 130 lbs | Assembled |
| 205623 | 1191 | 1″MNPT | 60% Gd Poly Styrene crosslinked with 40% DVB | 12 x 52 | 2 | 1 | 8.0 gpm | 16.0 gpm | 190 lbs | Assembled |
| 205624 | 1191 | 1″MNPT | 60% Gd Poly Styrene crosslinked with 40% DVB | 13 x 54 | 2.5 | 1 | 9.0 gpm | 17.0 gpm | 215 lbs | Assembled |
| 205625 | 1191 | 1″MNPT | 60% Gd Poly Styrene crosslinked with 40% DVB | 14 x 65 | 3 | 1 | 11.0 gpm | 18.0 gpm | 215 lbs | Assembled |
| 205626 | 1191 | 1″MNPT | 60% Gd Poly Styrene crosslinked with 40% DVB | 16 x 65 | 4 | 1 | 14.0 gpm | 20.0 gpm | 320 lbs | Assembled |
